A3 Carbon steel Water Treatment Tank Quartz Sand Multi Media Filter

  • Place of Origin:Guangdong, China (Mainland)
  • Brand Name:HJ
  • Certification:ISO 9001,ISO45001,ISO14001,CE
  • Model Number:Customized
  • Minimum Order Quantity:1 Unit/Units
  • Packaging Details:Carton or Wooden case
  • Delivery Time:7-10days after payment arrived
  • Payment Terms:L/C, D/A, D/P, T/T, Western Union, MoneyGram
  • Supply Ability:1000 sets per year
Contact Now Chat Now

A3 Carbon steel Water Treatment Tank Quartz Sand Multi Media Filter

Description

Material: A3 Carbon Steel

Size: φ3400*L1800(Based On Your Requirements And Application)

Filling Material: Quartz Sand, Activated Carbon, Anthracite, Resin, Etc.

Pack: Plastic Bottle

Performance: Precision Filtration,high Efficiency Filtration

High Light: A3 Carbon Steel Water Treatment Tank, Quartz Sand Water Treatment Tank

φ3400 L1800 Large Multi-media filter & Quartz sand filter



A3 carbon steel epoxy anticorrosion, φ3400, L1800, thickness 6mm, 15mm filter plate

Scope of application of quartz sand filter

It is suitable for the filtration of drinking water and other water purification treatments, and it is more suitable for the pre-treatment and circulating water treatment of production water in petroleum, chemical industry, mining, metallurgy, thermoelectricity, printing and dyeing, tanning, food, etc., as well as the recycling of sewage.

Other uses of quartz sand: Quartz sand is used to make glass, refractory materials, ceramics, smelting ferrosilicon, floor, architectural coatings, casting, grinding, etc.



Technical parameters of quartz sand filter:

1. Design filtration rate: 8-12m/h. When the head loss is about 5m, backwash regeneration is required (usually by reading the pressure difference between the inlet and outlet at 0.05MP).

2. Anti-cleaning intensity: 10-15L/sec•m².

3. Rinsing duration: 5-7 minutes

4. Inlet water pressure: ≥0.4Mpa Backwashing water pressure: ≥0.20Mpa

5. The expansion rate is 25%-50%.



Quotation of Quartz Sand Filter

Quotation of quartz sand filter, our factory produces quartz sand filter mainly by calculating steel cost, labor cost, tax and reasonable profit to determine the price of quartz sand filter. The main materials are upper head, lower head and upper cloth. Water tank, lower water distributor, manhole, discharge port, outriggers, lifting lugs, welding wire, material loss, etc. and internal anti-corrosion treatment, external surface treatment (carbon steel outer surface primer anti-rust paint, top coat can be based on According to customer requirements, the stainless steel is generally polished or matted). The quotation of the complete set of quartz sand filter needs to be configured according to customer requirements to configure the body pipe valve parts (such as backwashing, forward washing, running operation pipelines and valves) and quartz sand filter material to calculate. The pipeline and valve parts can also be provided with drawings and instructions. The buyer connects by himself, and the quartz sand filter material is provided by the buyer to purchase the quartz sand filter, thus saving the buyer's purchase cost.


Company Information

Foshan Hongjun Water Treatment Equipment Co.,Ltd - Water Treatment Professor

Foshan Hongjun Water Treatment Equipment Co.,Ltd is a professional water treatment equipment manufacturer with more than 15 years experience, specializing in water treatment design, manufacture, installation, technologu development and also sales support in this lin.

Our philosophy is "Usig the most advanced technology, provide the highest quality enginering and the best service at most reasonale price".



We look forward to cooperating with you.



Tag: activated carbon filter tank, pressure filter tank, sand filter tank replacement
