SUS316L Stainless Steel Water Treatment Tank Customization Specifications

  • Place of Origin:Guangdong, China (Mainland)
  • Brand Name:HJ
  • Certification:ISO 9001,ISO45001,ISO14001
  • Model Number:Customized
  • Minimum Order Quantity:1 Unit/Units
  • Price:Negotiable
  • Packaging Details:1000 sets per year
  • Delivery Time:30-40DAYS
  • Payment Terms:L/C, D/A, D/P, T/T, Western Union, MoneyGram
  • Supply Ability:Carton or Wooden case
Contact Now Chat Now

SUS316L Stainless Steel Water Treatment Tank Customization Specifications

Description

Body Material: SS304/316

Capacity: Customized

Usage: Water Tank / Sand Carbon

Canister Thickness: 6mm

Installation: Easy

High Light: SUS316L Water Treatment Tank, 6mm Thickness Steel Water Treatment Tank, Water Purification Tank Customization



The main features of quartz sand filter

Quartz sand filter equipment has a simple structure and is more convenient to run backwashing. It is mainly through adjusting 4 valves to change the direction of water. During operation, it is up and down, and for backwashing, it is in and up and out, and then the backwash is reversed through the blowdown valve. The washing sewage is discharged, and then the washing is carried out until the effluent is clear and clean. The quartz sand should be filled with: the size of the dirt interception layer of quartz sand is 0.5-1.0mm, the height is above 700mm, and there are two supporting layers underneath, which are 1 -2mm filling height is 150-200mm, 2-3mm filling height is 150-200mm. Untreated water has a pollution interception capacity of 0.5-1.0Kg/m3, and lime-treated water has a pollution interception capacity of 1.5-2.0 Kg/m3. For coagulated water, its pollution interception capacity is 2.5- 3.0Kg/m3.




Tag: activated carbon filter tank, pressure filter tank, sand filter tank replacement
