100T Cylindrical River Water Treatment Plant Water Automatic Filter

  • Place of Origin:Guangdong, China (Mainland)
  • Brand Name:HJ
  • Certification:ISO 9001,ISO45001,ISO14001
  • Model Number:Customized
  • Minimum Order Quantity:1 Unit/Units
  • Price:Negotiable
  • Packaging Details:Carton or Wooden case
  • Delivery Time:7-10days after payment arrived
  • Payment Terms:L/C, D/A, D/P, T/T, Western Union, MoneyGram
  • Supply Ability:1000 sets per year
Contact Now Chat Now

100T Cylindrical River Water Treatment Plant Water Automatic Filter

Description

Product Name: River Water Filtering Device

Production Capacity: 0.3-100000litre Per Hour

Material: Carbon Steel / Stainless Steel

Processing: Dosing,sedimentation,filtering

Usage: Filter River Water To Tap Water

Function: Water Purifying

High Light: Cylindrical River Water Treatment Plant, 100T River Water Treatment Plant, Stainless Steel River Water Treatment Plant



100T Cylindrical River Water Automatic Filter

Product Information

1. Overview:

In this water purification plant, raw water is from river. At the begnning, river water will b passed through all in one sedimentation device to remove some big particles, like suspended solid, mud and sand. Then flow to mechanical filters to remove susended solid, colloid and silt. At last to activated carbon filter to remove organic matter, residual chlorine, color, odor and some impurities. All the devices above are sonsist of a perfect pre-treatment system.

The whole system could be controlled automatically by relay, water level detector, pressure transducer or manually by man power. Usually, the system is set to be controlled automatically. The system could provide pure water continuously. It's easy, safe and reliable.



Chemicals dosing system:

PAC dosing device→Piping mixer

PAM dosing device→Pingping mixer

PH dosing device→Outlet from clean water tank

Bleaching powder dosing device→Outlet from clean water tank

1.Water Quality Compare

Inlet water/Water source: Turbidity≤3000mg/L

Product water quality; Turbidity≤3mg/L

2.Detail introduction:

1)Piping mixer:

Size:630*180*180mm

Material: Stainless steel material,better corrosion resistance

Function: mixing the chemicals PAC & PAM with water

2)Reaction tank:

Size:500*1500*6000mm

Material: Carbon steel

Function: Space for chemicals reacting with water,removing particles,suspended solids,etc.

3)Sedimentation tank:

Size:2000*1500*3000mm

Material: Carbon steel

Function: Space for flocculants sedimentation

4)Sand filter/Valveless filter:

Size:1500*1700*2000mm

Material: Carbon steel

Function: further purifying water.Valveless filter can backwash water automatically by gravity.

5)Clean water tank

Size:1500*1700*1000mm

Material: Carbon steel

Function: Final purified water will be stored here.
